ProDec Floor Scale

The ProDec floor scale is tough, accurate, affordable and suitable for most industrial weighing applications.

Overview

Available in mild and stainless steel, the ProDec floor scale is tough, accurate, affordable and suitable for most industrial weighing applications.

The stainless steel ProDec Floor Scale is equipped with hermetically sealed stainless Weigh Bars. The unique Weigh Bar sealing prevents air, gas and moisture from infiltrating gauge and wiring areas. This platform scale has been designed to withstand hard industrial environments and keep weighing reliably.  In fact, the steel top plate is welded to a steel support channel understructure. This then keeps the scale from warping and bending.

The ProDec Floor Scale uses exclusive Weigh Bar weight sensors for accuracy and reliability. The Weigh Bar’s unique design and solid steel milling protects the electronics, allowing greater weighing accuracy without reducing the strength.

The Weigh Bar is less prone to damage from impact and vibration, with a lower failure rate than conventional load cells.



It also has up to 200% end loading protection and is available in 5,000lbs, 10,000lbs and 20,000lbs capacities.

The stainless steel ProDec model was designed with the food and chemical industry in mind and is available in standard sizes ranging from 36”x36” to 84”x60” and capacities from 2,000lb to a more heavy-duty 10,000lb.

The stainless steel ProDec now includes side access to the stainless junction box which further reduces the chance of food, debris and other matter from getter trapped in the creases of the junction box compartment.

DSL7248-05

  • Height 3.31in
  • Maximum Capacity 5000lb
  • Weighing Increments 1lb
  • Power Source
  • Legal for Trade Capable Yes
  • Maximum Capacity 2500kg
  • Material 1/4" Steel Deck

DSL3030-05

  • Height 3.31in
  • Maximum Capacity 5000lb
  • Weighing Increments 1lb
  • Power Source
  • Legal for Trade Capable Yes
  • Maximum Capacity 2500kg
  • Material 1/4" Steel Deck

DSL3636-05

  • Height 3.31in
  • Maximum Capacity 5000lb
  • Weighing Increments 1lb
  • Power Source
  • Legal for Trade Capable Yes
  • Maximum Capacity 2500kg
  • Material 1/4" Steel Deck

DSL4848-05

  • Height 3.31in
  • Maximum Capacity 5000lb
  • Weighing Increments 1lb
  • Power Source
  • Legal for Trade Capable Yes
  • Maximum Capacity 2500kg
  • Material 1/4" Steel Deck

DSL6048-05

  • Height 3.31in
  • Maximum Capacity 5000lb
  • Weighing Increments 1lb
  • Power Source
  • Legal for Trade Capable Yes
  • Maximum Capacity 2500kg
  • Material 1/4" Steel Deck

DSL6060-05

  • Height 3.31in
  • Maximum Capacity 5000lb
  • Weighing Increments 2lb
  • Power Source
  • Legal for Trade Capable Yes
  • Maximum Capacity 2500kg
  • Material 1/4" Steel Deck

DSL4848-10

  • Height 4.06in
  • Maximum Capacity 10000lb
  • Weighing Increments 2lb
  • Power Source
  • Legal for Trade Capable Yes
  • Maximum Capacity 5000kg
  • Material 1/4" Steel Deck

DSL6048-10

  • Height 4.06in
  • Maximum Capacity 10000lb
  • Weighing Increments 2lb
  • Power Source
  • Legal for Trade Capable Yes
  • Maximum Capacity 5000kg
  • Material 1/4" Steel Deck

DSL7248-10

  • Height 4.06in
  • Maximum Capacity 10000lb
  • Weighing Increments 2lb
  • Power Source
  • Legal for Trade Capable Yes
  • Maximum Capacity 5000kg
  • Material 1/4" Steel Deck

DSL6060-10

  • Height 4.06in
  • Maximum Capacity 10000lb
  • Weighing Increments 2lb
  • Power Source
  • Legal for Trade Capable Yes
  • Maximum Capacity 5000kg
  • Material 1/4" Steel Deck

DSL7260-10

  • Height 4.06in
  • Maximum Capacity 10000lb
  • Weighing Increments 2lb
  • Power Source
  • Legal for Trade Capable Yes
  • Maximum Capacity 5000kg
  • Material 1/4" Steel Deck

DSL8460-10

  • Height 4.06in
  • Maximum Capacity 10000lb
  • Weighing Increments 2lb
  • Power Source
  • Legal for Trade Capable Yes
  • Maximum Capacity 5000kg
  • Material 1/4" Steel Deck

DSL9672-10

  • Height 4.06in
  • Maximum Capacity 10000lb
  • Weighing Increments 4lb
  • Power Source
  • Legal for Trade Capable Yes
  • Maximum Capacity 5000kg
  • Material 1/4" Steel Deck

DSL8472-10

  • Height 4.06in
  • Maximum Capacity 10000lb
  • Weighing Increments 2lb
  • Power Source
  • Legal for Trade Capable Yes
  • Maximum Capacity 5000kg
  • Material 1/4" Steel Deck

DSL6060-20

  • Height 5in
  • Maximum Capacity 20000lb
  • Weighing Increments 4lb
  • Power Source
  • Legal for Trade Capable Yes
  • Maximum Capacity 10000kg
  • Material 1/4" Steel Deck

DSL8460-20

  • Height 5in
  • Maximum Capacity 20000lb
  • Weighing Increments 4lb
  • Power Source
  • Legal for Trade Capable Yes
  • Maximum Capacity 10000kg
  • Material 1/4" Steel Deck

DSL9672-20

  • Height 5in
  • Maximum Capacity 20000lb
  • Weighing Increments 4lb
  • Power Source
  • Legal for Trade Capable Yes
  • Maximum Capacity 10000kg
  • Material 1/4" Steel Deck

DSLS3636-05

  • Height 3.31in
  • Maximum Capacity 5000lb
  • Weighing Increments 1lb
  • Power Source
  • Legal for Trade Capable Yes
  • Maximum Capacity 2500kg
  • Material 1/4" Steel Deck

DSLS8460-10

  • Height 4.06in
  • Maximum Capacity 10000lb
  • Weighing Increments 1lb
  • Power Source
  • Legal for Trade Capable Yes
  • Maximum Capacity 5000kg
  • Material 1/4" Steel Deck

DSLS6060-10

  • Height 4.06in
  • Maximum Capacity 10000lb
  • Weighing Increments 2lb
  • Power Source
  • Legal for Trade Capable Yes
  • Maximum Capacity 5000kg
  • Material 1/4" Steel Deck

DSLS6060-05

  • Height 3.31in
  • Maximum Capacity 5000lb
  • Weighing Increments 1lb
  • Power Source
  • Legal for Trade Capable Yes
  • Maximum Capacity 2500kg
  • Material 1/4" Steel Deck

DSLS7248-05

  • Height 3.31in
  • Maximum Capacity 5000lb
  • Weighing Increments 1lb
  • Power Source
  • Legal for Trade Capable Yes
  • Maximum Capacity 2500kg
  • Material 1/4" Steel Deck

DSLS6048-05

  • Height 3.31in
  • Maximum Capacity 5000lb
  • Weighing Increments 1lb
  • Power Source
  • Legal for Trade Capable Yes
  • Maximum Capacity 2500kg
  • Material 1/4" Steel Deck

DSLS4848-05

  • Height 3.31in
  • Maximum Capacity 5000lb
  • Weighing Increments 1lb
  • Power Source
  • Legal for Trade Capable Yes
  • Maximum Capacity 2500kg
  • Material 1/4" Steel Deck
